8000cd/m2 3000Hz Mobile Truck LED Display Full Color High Resolution

I'm Online Chat Now

8000cd/m2 3000Hz Mobile Truck LED Display Full Color High Resolution

8000cd/m2 3000Hz Mobile Truck LED Display Full Color High Resolution
8000cd/m2 3000Hz Mobile Truck LED Display Full Color High Resolution 8000cd/m2 3000Hz Mobile Truck LED Display Full Color High Resolution 8000cd/m2 3000Hz Mobile Truck LED Display Full Color High Resolution

Large Image :  8000cd/m2 3000Hz Mobile Truck LED Display Full Color High Resolution

Product Details:
Place of Origin: Shen Zhen China
Brand Name: OEM
Certification: CE RoHS
Model Number: OEM
Payment & Shipping Terms:
Minimum Order Quantity: 5sqm
Price: Negotiable
Packaging Details: Flight case, Plywood case
Delivery Time: 10 working days after receiving the payment
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 10K sqm per month

8000cd/m2 3000Hz Mobile Truck LED Display Full Color High Resolution

Description
Name: Mobile Truck LED Display Resolution/mm: 4
Color Temperature: 6500K-9500K Pixel Density/pixels/m²: 62500/m²
White Balance Brightness: >8000cd/㎡ Application: Promotional Activities / Public Relations Activities,
High Light:

3000Hz Mobile Truck LED Display

,

3000Hz vehicle led display

,

8000cd/㎡ Mobile Truck LED Display

8000cd/㎡ 3000Hz Mobile Truck LED Display Full Color High Resolution​

Features
* Colorful:Full color LED screen consists of a number of red, green and blue LED lights composed, which form a variety of colors, can achieve high resolution effect.

* Modular design:Standardized design of the module display unit, can be arbitrarily combined, according to the needs of customers.

* Control:You can set up the content and format you want to play, and then control the screen to play around, which requires an asynchronous system.

* Multiple options:The mobile LED screen could play various multimedia files, such as picture,images,video ,animation and so on.It can also be translated into local languages according to their request with the same quality.

* Anti-shake:During the movement of the truck, it is inevitable to meet the poor road conditions. Therefore, this display adopts a shockproof material to protect the display,extended the life span of led display.

* Low Consumption, long life time:The average power consumption of 300w / m²,The life time of the led display can reach 10000 hours.

* Effective:Advertising is not subject to time and place restrictions,it owns a wide range of audiences and it is convenient and flexible.Actually,it
spend a lower cost but obtains a better effect.


Applications of LED Display
Mobile Truck LED Display is being an important advertising media for outdoor events and advertising campaign on basis of its unique advanced structure feature.It’s known as truck mounted LED display and trailer mounted LED screen.The products are widely use for advertising,shows,square,concert, sporting event, festival, corporate gathering or charitable event,Grand Theater, large song and dance party, fashion show.


Product specification

outdoor P4mm LED Display
Lamp size 2727
Resolution/mm 4
Pixel configuration RGB 3 in 1
Pixel density/pixels/m² 62500/m²
Module resolution 64x32
Module size/mm 256*128MM
View distance ≥3m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >8000cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 14 bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:5km
Driving mode Constant driving current
Scanning mode constant driving static
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss

Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃ Storing temperature range: -30-65℃
Maximum power:/㎡ <750W
Average power:/㎡ <300W
Self-check technology

LED spot self-check, communications check, power check,
temperature monitor(need customization)

Remote monitoring

Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)

Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%



Our service:
1). Your inquiry related to our products or prices will be replied in 24hrs.
2). Well-trained and experienced staffs to answer all your enquires in fluent English .
3). OEM&ODM, any your customized screen we can help you to design and put into product.
4). are offered for your unique design and some our current models .
5). Protection of your sales area, ideas of design and all your private information





FQA:

  • What is the payment method?
  • We support a variety of payment methods, the most common is the TT;
  • How about your production ability?
  • We have 10 production lines with all series of automatic production machines. Monthly production ability: 200,000pcs of led modules and 4,000sqm of assembled led displays;
  • What's the controlling system?
  • Our standard controlling system for this model is Linsn/ Novastar. Also support other controlling system,like HD,Xixun,TF, Colorlight, etc;
  • Are you manufacturer or trading company?
  • We are manufacturer with professional marketing and service team;
  • Besides this product, may I have other options?
  • Yes, my dear friend. Many thanks for finish the details of this product. If it is not what you're looking for, you can also choose other items. we have HD indoor led display, full color for outdoor and indoor; Different cabinet, Steel Cabinet, Aluminum Cabinet, Die Cast Aluminum Cabinet, etc; The pixel pitch is from 1.5mm to 20mm. We also have LED advertising player and kinds of video processor;
  • Can it play HD video?
  • Yes, it can realize HD video function with Linsn/nova controlling system;
